5
77 |
Building Technologies
5.12.5 Testing indicators
The display test is a functional hardware check for the following indication
elements:
● Display
● LEDs
● Buzzer
At the same time, indication and operation devices that have been installed as
options, e.g. the mimic display driver or fire brigade operating panels, are activated
by commands if they offer the possibility of performing a display test.
The test takes 10 seconds and has two phases of 5 seconds each.
Depending on the configuration, the '
' command is available as softkey in
the 'Main menu'.
Testing the indicators and displays
1. Select 'Main menu' > 'Settings/administration'.
2. Select 'LED test'.
Phase 1 starts:
Display is totally white.
LEDs are in color mode 1.
Phase 2 starts:
Display is totally black.
LEDs are in color mode 2.
