Siemens FC7xx User Manual

Operation
Execute commands
–
Basics
5
65 |
184
Building Technologies
A6V10211076_i_en_
--
Fire Safety
2015
-
12
-
15
Topology
Exit with <C>
Access level 2.1
Detection tree
Hardware tree
↑ Control tree
(1)
(2)
(3)
Function
On/Off
Function
All
LED
test
κ Select 'Detection tree', continue with <ok>
001 Element Detection tree
Area 2 Portaphone AG
Lower
level
Execute
Commands
κ Select ''Area 2', continue with 'Lower level' <softkey 2>
005 Elements
Portaphone AG
Area 2
↑ Section
Section
Section
Section
1
2
3
4
Ground floor
1st floor
1st floor / EDP room
2nd floor
Upper
level
Lower
level
Execute
Commands
κ Select 'Section 1', continue with 'Lower level'' <Softkey 2>
005 Elements
Ground floor
Section 1
Zone
Zone
Zone
Zone
1
2
3
4
Reception hall
Corridor
Warehouse
Reception hall
Upper
level
Lower
level
Execute
Commands
κ Select 'Zone 1', continue with 'Lower level'' <Softkey 2>

Siemens FC7xx Specifications

General

Brand	Siemens
Model	FC7xx
Category	Control Panel
Language	English
