Op
eration
Switching off / Switching on
5
55 |
184
Building Technologies
A6V10211076_i_en_
--
Fire Safety
2015
-
12
-
15
004 Elements
Standard alarming controls
Alarmg. 1
IntS.Ct
RT fire
ExtS.Ct
RTfault
1
1
2
2
Internal sounder
Remote transmission channel FIRE
External sounder
Remote transmission channel FAULT
Upper
level
Lower
level
Execute
Commands
κ Select 'RT fire', continue with <ok>
002 Elements
Remote transmission channel FIRE
RT fire 1
Effects
Causes
1
1
Upper
level
Lower
level
Execute
Commands
κ Select 'Effects', continue with <ok>
001 Element Effects
RT ch. 1
Upper
level
More
Options
κ Continue with <More Options>
Selecting option
Execute commands
Jump to link
Show details
(3)
(4)
(5)
κ Select 'Execute commands' option, continue with <ok>
