Siemens FC7xx User Manual

Operation
Auto
-
configure line
5
95 |
184
Building Technologies
A6V10211076_i_en_
--
Fire Safety
2015
-
12
-
15
Example of ↑ auto-configuration
Main menu
Exit with <C>
Access level 3
Message summary
Functions
Favorites
Topology
(1)
(2)
(3)
(4)
Element search
Event memory
Login/logout
Settings/administration
(5)
(6)
(7)
(8)
Function
On/Off
Function
All
LED
test
κ Select 'Topology', continue with <ok>
Topology
Exit with <C>
Access level 3
↑ Detection tree
Hardware tree
↑ Control tree
(1)
(2)
(3)
Function
On/Off
Function
All
LED
test
κ Select 'Hardware tree', continue with <ok>
001 Element Hardware tree
Station 1 Main building
Lower
level
More
Options
κ Select 'Station 1', continue with 'Lower level' <softkey 2>
005
FC2020
Elements
Main building
Station 1
Module
Module
Module
Module
1
2
3
4
Onboard I/Os
C-NET line card (onboard/FCL2001)
C-NET line card (onboard/FCL2001)
Communication interfaces
Upper
level
Lower
level
More
Options
κ Select 'Module 2', continue with 'Lower level'' <softkey 2>
