FS-100 Installation & Operation Manual
P/N 315-699461 18
CONTROL UNIT INSTALLATION
PARTS SUPPLIED
Back-box Assembly (black or red) Door Assembly (black or red)
Transformer Assembly (120VAC) #6-32 Locking Nuts (6)
Front Plate Assembly #6-32 x 1/4” Screws (16)
Main Board #8-32 Self-tapping Screw, (4)
Display Board 24K Ohm 1/2W Resistor (4)
Cable Assembly, 16 Pin Screwdriver
Clear Lexan Window Owner’s Manual
Overlay Operating Instructions
Programming Keypad 120 Ohm 1/2W Resistor (2)
The fire alarm control unit must be mounted in a properly accessible location as required by applicable
codes. Any auxiliary battery box or other accessory not connected through a protective device or a circuit
designed for remote connection must be within the same room and connected through electrical conduit.
Installation is to be done only by qualified personnel who have thoroughly read and understood these
instructions.
CAUTION
It is recommended that the printed circuit boards be removed for any procedure that may cause dust,
metal shavings, grease or any such matter that may affect the circuit boards and/or parts. There may be
several sources of power into the control unit. Each source must be disconnected prior to installing or
removing modules, connecting or disconnecting wiring, and programming jumpers.
CONTROL UNIT LOCATION
The control unit should be located near an exit at ground level, where the normal ambient temperature is
maintained within the control unit specification (See General Specifications in Section III). The unit
should be in an area that is free of dust, vibration, moisture and condensation.
ENCLOSURE MOUNTING
Follow the appropriate instructions for surface or semi-flush mounting.
