FS-100 Installation & Operation Manual
P/N 315-699461 25
SYSTEM WIRING
Basic system wiring and detector siting must be in accordance with NFPA 72 or other instructions from
the appropriate local authority. Unit connections and limitations are as indicated on the wiring diagram
included below.
Devices that may be satisfactorily used with the control unit are shown in the compatible device listing in
Appendix B.
Wire reference data are included in Appendix A.
CONTROL UNIT WIRING OVERVIEW
The overall arrangement of boards in the control unit is shown in the following diagram.
2*
3
1
2. FS-DACT board or FS-MT board
* (Note: When using FS-DACT, the FS-232 cannot
be used)
3. FS-232 RS-232 Interface Board
