FS-100 Installation & Operation Manual
P/N 315-699461 35
PROGRAMMING THE CONTROL UNIT
MAIN BOARD JUMPER
Factory setting is shown.
P1 – Addressable Device Circuit Wiring Style
• Style 6/7
•
• Style 4
KEYPAD PROGRAMMING
Customized programming of the FS-100 control unit may be accomplished through a keypad included in
the control unit. A sixteen-key, telephone-style keypad mounts on the front panel within the cabinet. The
keypad may also be easily removed if desired. See the Siemens Programmer’s Manual (P/N 315-
699490) for detailed information of system programming.
PROGRAMMING SECURITY
The following levels of security protect the system from unauthorized use:
• User – Locked Door
• Maintenance – Locked Door and 4-digit Maint Password
• Technician – Locked Door and 5-digit Tech Password
The User and Maintenance Levels are also accessible from the Remote LCD Annunciator.
