P/N 315-699461 44
B. System Troubles
ENTRY INDICATES
AC Trouble AC input low or off
AddrLp 1 DBLSHT Double short trouble on addressable loop 1
AddrLp 1 OPEN Open circuit trouble on addressable loop 1
AddrLp 1 SHORT Short circuit trouble on addressable loop 1
BATT Trouble Battery input low or off
CITY Trouble Local Energy circuit open
CM1aa NoRespons Programmed control module not responding on loop 1 at address aa
CM1aa DataError More than one device responding on loop 1 at address aa
CM1aa OPEN Control module NAC wiring open on loop 1 at address aa
CM1aa SHORT Control module NAC wiring shorted on loop 1 at address aa
DACT Acct Trb DACT account reporting trouble
DACT Com Trouble DACT communication trouble with main processor
DACT PL x Trouble Open or short on DACT phone line x
FLASH FATAL Trb Configuration Flash memory trouble
GRND FAULT Trbl Ground Fault trouble
LCDxx NoRespons LCD Annunciator xx programmed but is not responding
LCDxx Not Pgmd LCD Annunciator xx is not programmed but is responding
LCDxx Trouble LCD Annunciator xx reports trouble
ADD00 Addr=00 Device on the loop responded to address 00
ADDaa Not Pgmd Device responding is not programmed on loop address aa
ADDaa NoRespons Device not responding
ADDaa Mult. Add Resp More than one device responding on the loop at address aa
ADDaa Com Trb Device responses are not valid on the loop address aa
ADDaa Inc. Dev. ID Device responding is not the type programmed on the loop address aa
ADDaa OPEN Device IDC wiring open on loop 1 address aa
ADDaa Tst Flt Detector is not entering or exiting test mode on loop address aa
ADDaa TRBL Sensor needs maintenance on loop 1 address aa
ADDaa MaintAlrt Sensor needs cleaning on loop 1 address aa
ADDaa TestValue Not receiving valid sensor test reading on loop l address aa
MNLP Bad Msg Main processor to loop processor communication trouble
MNLP Fifo Xmit Main processor to loop processor communication trouble
MNLP NoRespons Main processor to loop processor communication trouble
NACxx Trouble NAC xx wiring is open or shorted
PC Pgmr Trb Control unit is not receiving communication from PC
QuickTest Abort Quick Test Timer expired causing abnormal exit of Quick Test
Trb Reminder Trouble Reminder timer expired
RD 33 LED on serial annunciator board trouble
