Siemens FireSeeker FS-100 User Manual

FS-100 Installation & Operation Manual
P/N 315-699461 40
BATTERY SIZE CALCULATIONS
Standby Current (A.) Alarm Current (A.)
FS-100 Control Unit 0.110 0.200
FS-MT Municipal Tie
Module
Standby 0.005 0.005 + NA
Alarm 0.028 0.028 NA +
Standby (note 5) + NA
Alarm (note 5) NA +
FS-232 RS232
Module
Standby 0.008 0.008 + NA
Alarm 0.008 0.008 NA +
FS-DACT Module Standby 0.038 0.038 + NA
Alarm 0.054 0.054 NA +
FS-RD Remote Standby 0.020 X = + NA
Annunciator Display Alarm 0.030 X = NA +
FS-RU Serial Standby 0.010 X = + NA
Relay Unit Alarm 0.170 X = NA +
FS-RE16 Serial Standby 0.000 X = + NA
Relay Extender Alarm 0.160 X = NA +
FS-SAU Serial Standby 0.015 X = + NA
Annunciator Unit Alarm (note 4) 0.040 X = NA +
FS-SAE16 Serial Standby 0.005 X = + NA
Annunciator Ext. Alarm (note 4) 0.000 X = NA +
Addressable Devices
Catalog # Quantity X Current (A.)
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
End of Line Relay
Catalog # Quantity X Current (A.)
X = + +
Notification
Appliances
Catalog # Quantity X Current (A.)
X = NA +
X = NA +
X = NA +
X = NA +
Other (Aux. DC) = + +
TOTAL
