FS-100 Installation & Operation Manual
P/N 315-699461 39
Addressable Device Circuit Wire Selection Guide
Each addressable device circuit must meet the following requirements:
• Total loop resistance - 40 ohm maximum.
• Total loop capacitance - 0.28uF maximum (56pF/ft. max.)
• Twisted pair wire.
• Unshielded cable.
• Low capacitance cable.
• High velocity of propagation cable - 60% minimum.
• Each loop runs separate from all other circuits.
• Run + out and - out separately from + in and - in.
• Different models or types of cable should not be in the same loop.
Maximum Wire Loop Distance (Feet)
(Includes all branches of a Style 4 loop)
Wire size: 18AWG 16AWG 14AWG * 12AWG
Wire length: 6150 9750 10,000 10,000
Cable length: 3075 4875 5,000 5,000
* The terminal blocks on the FS-100 are rated for a maximum of 14AWG wire.
