4.2 Description
Signal type
B Bi-directional signal
O Signal output
V Supply voltage
I Signal input
VI Voltage input
VO Voltage output
K Contact
X3: Ethernet connection
The Ethernet interface is compatible to the 10/100/1000BASE-T IEEE 802.3 standard, without
crossover function.
Connector designa‐
tion:
X3
Connector type: 8-pole RJ45-socket with interlock (above)
Pin assignment The pin assignment corresponds to the standard, see "General infor‐
mation and networking" → "Connecting".
X5: USB interface
The USB interface corresponds to the USB 1.1 specification with full speed data rate.
Connector designa‐
tion:
X5
Connector type: Type A socket
Pin assignment The pin assignment corresponds to the standard, see "General infor‐
mation and networking" → "Connecting".
NOTICE
Damage to the plug by missing protective cap
Replace the USB connector if its protective cap is torn, because in this case, the connector
is no longer protected from dirt.
NOTICE
Damage to the inserted USB FlashDrive should the HT 8 fall
A plugged-in USB FlashDrive can be damaged or broken off if the device falls.
Interfaces
4.2 Description
Handheld Terminal HT 8
102 Manual, 07/2015, A5E36371621B-AB
