Connecting
5
5.1 Overview
Connection box
PN Basic /
PN Plus
Connection
module
Basic PN
USB
interface
Ethernet cable
or
or
Article no.
Prefabricated cable
Emergency stop / enabling circuit
Emergency stop / enabling circuit
Emergency stop / enabling circuit
6XV1440-4B...
6FC5348-0AA08-3AA0
SINUMERIK
PCU 50.5
SINUMERIK
MPP 310 IEH/
MPP 483 IEH/
MPP 483 HTC
SINUMERIK
NCU 7x0.3 PN
SINUMERIK
Handheld
Terminal
HT 8
Figure 5-1 Connection overview HT 8
The HT 8 is designed for communication in an Ethernet network. The following connection
options are available:
● PN Basic terminal box/PN Plus terminal box
● PN Basic connection module (for control cabinet installation) or
● MPP 310 IEH / MPP 483 IEH / MPP 483 HTC
HT 8 with
PN Basic/PN Plus terminal box PN Basic connection module MPP 483 HTC
6DIHW\
VLJQDOV
(WKHUQHW
(WKHUQHW
(WKHUQHW
6DIHW\
VLJQDOV
(WKHUQHW
(WKHUQHW
(WKHUQHW
6DIHW\
VLJQDOV
(WKHUQHW
(WKHUQHW
(WKHUQHW
Connection via the PN Plus terminal box allows quick connection and disconnection during
machine operation without an emergency stop being triggered.
