Technical data
6
Safety
Safety class III; PELV according to EN 50178
Degree of protection accord‐
ing to EN 60529
Front side IP65
Rear side IP00
Approvals CE / cULus
Electrical data
Power consumption
(without load at USB interface,
without direct key module)
typically approx. 5 W
maximum approx. 6 W
Mechanical data
Dimensions Width: 483 mm Height: 310 mm Depth: 30 mm
Weight Approx. 5 kg
Tightening torques, max. Tension jack screws:
0.5 Nm
M3 screws:
0.8 Nm
M4 screws:
1.8 Nm
Display
Size / resolution 12.1" TFT / 800 x 600 pixels
Backlight-service life typ. 50,000 h at 25º C (dependent on the temperature)
Note
Information about the climatic and mechanical environmental conditions is contained in the
associated section under:
"General notes and interconnection" → "Operational planning".
Operator panel front: OP 012
Manual, 09/2016, A5E36371591B 103
