The following user-specific files are required. You can use the sample files as template:
File Meaning
"sljkconfig.ini" configuration file File in which the traversing keys are configured.
Text file "oem_sljk_xxx.ts" File for labeling traversing keys in a foreign language, xxx =
language code
"sljkconfig.ini" configuration file
Entries Meaning
[State_1] Labeling type - changed via the PLC.
ParamText_x_y Text of the traversing key that is made up of parameters.
Two-line labeling is possible, whereby max. five characters are possible per line.
x: Specifies the position of the key within the row (2 to 7).
y: Specifies the key row (1 or 2).
%m1 The machine axis name of the first axis is referenced and displayed as
text. The current active axis number is read out from data block DB10.
The name from the machine data is determined via this index.
%n Defines the position in the text for the line break.
%a1 The alias axis name of the first axis is referenced and displayed as text.
The current active axis number is read out from data block DB10. The
name from the "oem_sljk_eng.ts" text file is determined via this index.
TextId_x_y Text of the traversing key that is read from the text file (target language text).
Picture_x_y File name of the icon to be displayed.
The files with the icons must be located in the following directories: /oem/sinumerik/
hmi/ico and
depending on the resolution of the subdirectories:
/ico640
/ico800
/ico1024
/ico1280
Procedure
1. Copy the "sljkconfig.ini" configuration file from the folder
/siemens/sinumerik/hmi/template/cfg
2. Place the copy into the folder /oem/sinumerik/hmi/cfg
or /user/sinumerik/hmi/cfg
3. Open the copy in the Editor and define the traversing key labeling.
Example of a "sljkconfig.ini" configuration file
12 axes are defined in the example, with text for softkey 1 and softkey 2, as well as an image
on softkey 3 and softkey 4.
[Settings]
FileType = INI
Commissioning
6.1 SINUMERIK Operate
Handheld Terminal HT 8
124 Manual, 07/2015, A5E36371621B-AB
