Dimension drawing







Figure 10-2 HT 8 wall holder - dimension drawing
Note
Please note that the holder is smaller than the HT 8 (∅ approx. 290 mm). You must keep
sufficient clearance around the holder to ensure convenient handling.
Accessories
10.2 Wall holder
Handheld Terminal HT 8
Manual, 07/2015, A5E36371621B-AB 149
