Sequence for a TCU
Procedure:
1. Connect TCU.
This opens the dialog "New operator panel (TCU)".
2. Select "New" to connect a new TCU and "OK" to confirm.
3. In the next dialog, accept the name suggested by the system or enter a name and confirm
this with "OK".
The following parameters are pre-selected for the TCU:
Operator panel index - TCU [0-255]
Machine control panel address - MCP [0-255]
Electronic key system index - EKS [0-255]
Enable direct keys
1_
192
0
No
4. Restart the TCU to apply the new settings.
5. If you want to change the parameters, select "Main menu" ā "Service this panel" ā "Modify
operator panel settings".
General information and networking
1.4 Networking
Operator panel front: OP 012
56 Manual, 09/2016, A5E36371591B
