Error
Code
Diag.
Code
Meaning for the LMV3 System Corrective Action
Note: Diagnostic codes are additive. If a diagnostic code appears that is not on this list, it is a combination of multiple diagnostic codes.
Any # Internal error - backup / restore
An error occurred while attempting to perform a backup or restore via
parameter 050. See diagnostic codes for more information.
157 (-99) Restore - ok, but backup < data set of current system
No fault: Restore was successful, but the backup data record is smaller
than in the current system.
239 (-17) Backup - storage of backup in AZL23 faulty Reset the fault and repeat the backup.
240 (-16) Restore - no backup in AZL23
There is no parameter set stored in the AZL23, so the restore process could
not be completed. Reset the fault.
241 (-15) Restore - abortion due to unsuitable product no. (ASN)
The parameter set stored in the AZL23 has an unsuitable product no.
(ASN), so the restore process was aborted. Reset the fault.
242 (-14) Backup - backup made is inconsistent
The backed up parameter set is faulty and cannot be transferred back to
the LMV3. Reset the fault.
243 (-13) Backup - data comparison between µCs faulty Reset the fault and repeat the backup.
244 (-12) Backup data are incompatible
The parameter set stored in the AZL23 is not compatible with the LMV3
software version, so the restore could not be completed. Reset the fault.
245 (-11) Access error to parameter Restore_Complete Reset the fault and repeat the restore.
246 (-10) Restore - timeout when storing in EEPROM Reset the fault and repeat the restore.
247 (-9) Data received are inconsistent
Some data in the parameter set stored in the AZL23 is invalid, so the
restore could not be completed. Reset the fault.
248 (-8) Restore cannot at present be made Reset the fault and repeat the restore.
249 (-7) Restore - abortion due to unsuitable burner identification
The parameter set stored in the AZL23 has an unsuitable burner
identification and must not be transferred to the LMV3. Reset the fault
and do not attempt the restore again.
250 (-6) Backup - CRC of one page is not correct
The restore was not possible because the backup data record is invalid.
Reset the fault.
251 (-5) Backup - burner identification is not defined
A valid burner ID (parameter 113) is required to perform a backup. Set the
burner ID, reset the fault, and start the backup again.
252 (-4) After restore, pages still on ABORT Reset the fault and repeat the restore.
253 (-3) Restore cannot at present be made Reset the fault and repeat the restore.
254 (-2) Abortion due to transmission error Reset the fault and repeat the restore.
255 (-1) Abortion due to timeout during backup / restore
Communication between the LMV3 and AZL23 was interrupted during the
backup or restore. Re-establish communication and reset the fault. If the
fault continues, it is possible the AZL23 is too old and does not support the
backup / restore functions. If this is the case, replace the AZL23.
137
Section 6 Page 19 SCC Inc.
