Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
For the complete parameter list, refer to section 6.5 «Menu and
parameter lists».
Menu selection
A main menu item is selected as follows:
Ope r a t i ona l S t a t
Ope r a t i on
Manua l Ope r a t i on
Params & Di sp l ay
Calling up and selection
To indicate a selection, the first letter of the menu item is shown with a flashing pointer.
As long as the selection is made by pressing the SELECT buttons within the 4 menu
items shown on the display, the selection scrolls.
If some other (presently not shown) menu item shall be selected, the menu display
scrolls.
Press ENTER to make the final selection.
This calling up and selection procedure is similar on all other menu levels.
Example:
Ope r a t i on
Manua l Ope r a t i on
Params & Di sp l ay
Upda t i ng
Changing the standard parameters
This action is shown using the example of setting the prepurge time of the burner control
section.
Selection of the associated main menu item:
The main menu item «Parameterization & Display» is called up and selected as
described above:
Ope r a t i ona l S t a t
Ope r a t i on
Manua l Ope r a t i on
Params & Di sp l ay
P
= flashing cursor
Standard parameteri-
zations (incl. entry of
password)
