Siemens LMV5 Series Basic Documentation

115/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
Sequence steps of adaption (self-setting):
1) Starting the adaption
Using the AZL5… menu, the heating engineer manually activates the adaption function
of the LC.
After selecting menu item «Adaption» (within the parameter settings of the LC), the
following display will appear:
− The pointer is positioned on «
Start adaption». Adaption is activated by pressing
ENTER
Start Adapt ion
wi th ENTER 60
Setpo i nt : 70 . 0°C
Act Val :60.0°C
Adaption starts after pressing ENTER whereupon the following text appears:
Adap t ac t i ve
Load :52 . 0%
Act Val :60.0°C
Cance l wi th ESC
Depending on the adaption step, the following displays appears, alternating with the
display shown above:
Adap t ac t i ve
Set t ing Phase
max . 1 0 mi n
Cance l wi th ESC
Adap t ac t i ve
Temp Setback
Act Val :60.0°C
Cance l wi th ESC
Adap t ac t i ve
Hea t i ng
max . 1 0 mi n
Cance l wi th ESC
Special function
adaption LC
