Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
STARTUP V (Phase 36)
Dr iving to
Ignition Pos 36
F65.1 L44.6 10.3
STARTUP VI (Phase 38)
Ignition Pos 38
F32.1 L42.3 22.3
STARTUP VII (Phases 40,42,44)
Fue l
Release 1 40
Flame 80%
F32.1 L42.3 22.3
STARTUP VIII (Phases 50,52)
Fue l
Release 2 50
Flame 80%
F32.1 L42.3 22.3
STARTUP IX (Phase 54)
Dr iving to
Low- f i re 54
F28.5 L38.3 18.5
OPERATION I (Phase 60)
Setpoint 125°C
Act Value 124°C
Set Load 57 . 5%
Flame 100%
OPERATION II (Phase 62)
Shut - down
Low- f i re 62
F28.5 L17.6 12.5
Display (cont‘d)
