Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
Below, the most important displays of «Normal operation» and examples of «Lockout
and start prevention messages» and «Parameter settings» are defined.
In «Normal operation», the display shown is the default display which automatically
appears and which is maintained as long as no settings are made and no unusual
events like faults or start preventions occur.
The change from other displays to the normal display can be made by pressing the Info
button.
If the commissioning procedure shall be watched, the display can be switched to
«Normal operation» by simultaneously pressing the select buttons «<» and «>» or the
«Info» button.
Normal operation (undisturbed, no manual entries)
HOME RUN (Phase 10)
LMV 5x
Home 10
Star t No 123456
F05.1 A02.4 04.3
STANDBY (Phase 12)
Setpoint 125°C
Act Value 124°C
Fue l Oi l
Standby 12
STARTUP I (Phases 20,21)
Wa i t i ng f o r
Star t Realase 21
F05.1 A02.4 04.3
STARTUP II (Phase 22)
Start
Fan on 22
F05.1 A02.4 04.3
STARTUP III (Phase 24)
Dr iving to
Pre-purging 24
F05.1 L44.6 30.3
STARTUP IV (Phases 30...34)
Pre-purging 32
F05.1 L94.6 98.3
Displays
