Setting multistage ratio control «Followed»
The startup is made similar to modulating operation, including automatic entry of the
ignition positions in the operating positions «Stage 1», if these still display invalid values
(showing: XXX.X as a value).
Punk t I Lu f t : 28 . 5
:BS1 IHilf1:28.4
O2 I :
4.3I :
For the fine adjustment of that point, confirm by pressing ENTER.
Punk t I
Luf t :28. 5
:BS1 IHilf1:28.4
O2 I :
4.3I :
This causes output stage 1 to be approached. Here, the actuator to be adjusted can be
selected. Again, confirm by pressing ENTER.
Punk t I Lu f t : 28
.5
:BS1 IHilf1:28.4
O2 I :
4.3I :
Now, the value can be changed and the respective actuator follows at the rate of the
set ramp speed.
ENTER saves the value and ESC rejects it.
In this way, all stages can be set one by one.
The following table shows the response of the system when a point is selected.
However, the relevant valve is switched on only when at least the switching on point is
definitely used (≠ XXXX).
Selected point Response Remark
Operating point stage 1 Approach of stage 1 Fine adjustment of stage 1
Switch-on point stage 1 Approach of stage 1 Setting from stage 1
Switch-off point stage 2 --
Setting from both stage 1 and
stage 2
Operating point stage 2 Approach of stage 2 Fine adjustment of stage 2
Switch-on point stage 3 Approach of stage 2 Setting from stage 2
Switch-off point stage 3 --
Setting from both stage 2 and
stage 3
Operating point stage 3 Approach of stage 3 Fine adjustment of stage 3
System response when a point is selected
