Siemens LMV5 Series Basic Documentation

Parameterdarstellung auf Basis der Menüstruktur AZL - Ebene «OEM» - Auslieferstand Siemens Landis&Staefa
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6 Description Value range Access
rights
Default
parameter
setting
LMV51 LMV52
147/278
Siemens Building Technologies Basic Documentation LMV51... CC1P7550en
HVAC Products 7 Display and operating unit AZL5... 01.10.2003
ACT4 included? Information: ACT4 included in last backup YES/NO No
Yes
User No x x
ACT5 included? Information: ACT5 included in last backup YES/NO No
Yes
User No x
ACT6 included? Information: ACT6 included in last backup YES/NO No
Yes
User No x
VSD included? Information: ACT1 included in last backup YES/NO No
Yes
User No x x
O2 included? Information: O2 included in last backup YES/NO No
Yes
User No x
LMV5x -> AZL Saving the parameters of the system on the AZL Service x x
AZL -> LMV5x Transferring the parameters saved on the AZL to the system Service x x
Load_SW_from_
PC
Updating the AZL software via the serial port with the PC tool Service x x
PW Login Obtaining access right via the password (access times can be
parameterized)
User x x
PW Logout Canceling the last access right obtained via password Service x x
SafetyCheckFunc
t
TÜV test User x x
LossFlameTest Loss of flame test Service x x
SLT Test Safety limit thermostat test deactivated
activated
User - x x
