Parameters
12.2 Relay/Alarm Function (P100 - P117)
BW500 and BW500/L
Operating Instructions, 12/2016, A5E33482052-AD
159
12.2.2
P101 High Alarm / Deviation Alarm
High Alarm (f = 100)
For relay functions, P100 = 1, 2, and 3, this parameter sets the high alarm setpoint for the relay
selected; BW500: relays 1 to 5 (P100 -01 to -05); BW500/L: relays 1 and 2 (P100 -01 to -02).
Enter the value in % of full scale.
Deviation Alarm (f = 10)
1)
For relay functions, P100 = 5 and 6, this parameter sets the deviation setpoint for the relay
selected; relays 1 to 5 (P100 -01 to -05).
Enter the value in % of setpoint.
Differential Speed (f = 110)
1)
For differential speed functions, P100 = 10, this parameter sets the high alarm setpoint for the
relay selected; relays 1 to 5 (P100 -01 to -05).
1)
Not available with the BW500/L.
12.2.3
P102 Low Alarm
Sets the low alarm setpoint for relay selected, BW500: relays 1 to 5 (P100 – 01 to – 05),
BW500/L: relays 1 and 2 (P100 – 01 to – 02) (f=20).
Enter the value in % of full scale
Note
Not applicable if P100 = 4, 5, 6, 7, or 8.
Differential Speed (f = 90)
1)
For differential speed functions, P100 = 10, this parameter sets the low alarm setpoint for the
relay selected; BW500: relays 1 to 5 (P100 -01 to -05).
1)
Not available with the BW500/L.
12.2.4
P107 Relay Alarms
Sets the alarm mode for the relay selected; BW500: relays 1 to 5 (P100 -01 to -05); BW500/ L:
relays 1 and 2 (P100 -01 to -02).
Entry:
1 = high and low f
2 = high only
3 = low only
Note
Not applicable if P100 = 4, 5, 6, 7, or 8.
