Siemens Milltronics BW500

To Next Page

To Previous Page

Installation

5.8 RS232 Port 1

BW500 and BW500/L

Operating Instructions, 12/2016, A5E33482052-AD

5.8

RS232 Port 1

5.8.1

Printers

①

Printer

②

Receive

③

Common

5.8.2

Computers and Modems

For connection to a PC compatible computer or modem, using no flow control, typical

configurations are:
