Installation
5.4 Interconnection
BW500 and BW500/L
Operating Instructions, 12/2016, A5E33482052-AD
27
Optional Components and their Locations
Route SmartLinx cable along right hand wall
Wiring may be run via common conduit. However, these may not be run in the same
conduit as high voltage contact or power wiring.
Ground shield at one point only.
Insulate at junctions to prevent inadvertent grounding.
To Next Page
