Installation
5.2 Layout
BW500 and BW500/L
Operating Instructions, 12/2016, A5E33482052-AD
23
Optional LVDT conditioner card
4)
Optional Analog I/O board
2)
1)
Optional SmartLinx module
3)
1)
Applicable for trade approvals.
2)
Not available for BW500/L.
3)
To reduce communication interference, route SmartLinx cable along right side.
4)
The LVDT card must be removed to access terminals below it.
