Start Up

6.4 Load Cell Balancing

BW500 and BW500/L

Operating Instructions, 12/2016, A5E33482052-AD

①

Test weight

Press the following key:

Load Cell Balancing C & D

Place weight at cell C and press ENTER

①

Test weight

Press the following key

Main Page
