Recalibration
7.4 Recalibration
BW500 and BW500/L
84 Operating Instructions, 12/2016, A5E33482052-AD
When span calibration is done, press the following key to revert to the
mode.
Rate kg/h
0.00 kg/h Multispan 2
For example: if there is no material on the belt and the conveyor is running. The current rate is 0 and
no material has been totalized.
When the material to be run on the belt changes, the multispan is changed to the corresponding
span. This is completed either by changing the span value entered in P365, or by closing the
appropriate contacts connected to the programmed Auxiliary inputs.
Multispan
Selection Aux 2
Multispan
Selection Aux 3
1
2
3
4
5
6
7
8
It may be required to reset or note the totalizer value, as the process materials being conveyed
change. Refer to Operation. (Page 97)
Linearization applies concurrently to spans.
