Technical data
10
Siemens Building Technologies
Fire Safety & Security Products 07.2008
4 Technical data
Power supply: 12 -24 V DC
Min. 10,5 V DC
Max. 35 V DC
Power consumption: Typ. 400 mW
17 mA@24V
33 mA@12V
Max. 1 W (while horn sounds)
IP class: IP54
Frequency range: EM: 125 kHz.
Cotag: 66-132 kHz.
Temperature range: -30° C to +50° C
Dimensions (HxWxD) mm: 140x80x40
If needed, complete the installation with flush mounting kit BB3.
4.1 Reading distances
EM4102 (passive): up to 5 cm.
Cotag (passive): up to 5 cm.
Cotag (active): up to 10 cm.
