11.2.2 Entro DC22 & DC12 connections
This is how to connect to an Entro DC22 or DC12 door controller. The BCLINK in-
terface is used and which is the factory setting for the PP500.
DC22 & DC12 Signal PP500
11
V+
1 V+
12
0V
2 0V
13
Com C
3 C (H)
14
Com D
4 D (D0)
Table 2 DC12 & DC22 connections
11.2.3 DC800 connections
This is how to connect to a DC800 door controller for Stand-alone or Entro Lite
use. The BCLINK interface is used and which is the factory setting for the PP500.
The jumpers in the DC800
shall be set as below:
J1 = Vin (incoming power).
J4 = BCLINK
DC800 Signal PP500
14
V+
1 V+
15
0V
2 0V
18
Com C
3 C (H)
19
Com D
4 D (D0)
Table 3 DC800 connections
