The following Mag Stripe data outputs are available:
Interface Number Function
47 5 Secondary Code characters (Secondary Code not checked), 5 data charac-
ters (lower 16 bits of data), 1.5ms bit period, 500µs strobe.
4D 5 Secondary Code characters, insert character “6”, 5 data characters (middle
16 bits of lower 32 bits of data), 1.5ms bit period, 500µs strobe.
4E 5 Secondary Code characters, insert character “6”, 5 data characters (lower 16
bits of data), 1.5ms bit period, 500µs strobe.
4F 5 Secondary Code characters, 5 data characters (lower 16 bits of data), 1.5ms
bit period, 500µs strobe.
BE with bit 32 of the card programmed to 0: 5 Secondary Code characters, 5 data
characters, 1.5ms bit period, 500µs strobe.
BE with bit 32 of the card programmed to 1: bottom 31 bits of card code are
converted to a decimal number and are then output as ten data characters,
1.5ms bit period, 500µs strobe (this interface is used for Bewator IB1 coded
cards).
With interface BE (bit 32 programmed to 0) and interfaces 47, 4D, 4E and 4F, sec-
ondary codes from 0 to 65535 and card numbers from 0 to 65535 are each output
as five decimal characters, ten characters in all, Secondary Code first, most signifi-
cant character first. It is best to use the Cotag Programmer in DD display format to
program the cards, but even if it is set up in HH and the Secondary Code or card
number contain hexadecimal digits A to F, the card will still work with the magnetic
stripe interface.
With interface BE (bit 32 programmed to 1), the bottom 31 bits of card code are
converted to a single decimal number which is then output as ten characters, most
significant character first.
13.5 4101/4010 Controller interface
The Readers can be connected to a 4422 swipe card module installed in a 4101 or
4010 Controller, or directly to a 4010 swipe Controller, the pin connections being
as follows:
Reader 4422 swipe module or 4010 swipe Controller
D0 D0
D1 D1
0V 0V
Interface Number Function
59 Wiegand output to 4422 swipe module
or 4010 swipe Controller
