General
7
Siemens Building Technologies
Fire Safety & Security Products 07.2008
1 General
The PP500 can be connected to many systems for example SiPass Entro and Si-
Pass Entro Lite, Granta and SiPass Integrated. The PP500 can be ordered in two
different variants supporting two different reading technologies:
z Cotag technology (both active & passive)
z EM4102 technology
Normally the four pre-configured modes are sufficient to fit all the need of an ac-
cess control system. However – the reader allows advanced re-configuring. See
chapter
12 Reconfiguring the function for more information.
1.1 Main Functions
z Support for Cotag Technology cards & tags (both active & passive).
z Support for EM4102 cards & tags.
z Distributor Code re-teachable (in Cotag Technology form).
z Configuration re-teachable by a configuration card.
z Pre-defined reader configurations enabled through the keypad.
z Jumper selectable Entry or Exit for BCLINK.
z Tamper Switch.
z External connectors for Tamper contact output.
z Backlit keypad.
z Wiegand, Clock & Data and BCLINK protocols supported.
z Internal, External (R, G, Only) and Single wire control of LED’s.
z Power supply 12-24V DC.
1.2 About this document
This document is mainly aimed for installers that want to customize the operation
of the PP500, e g to re-configure the card reading parameters.
The basic configuration and installation is also described in the PP500 Installation
guide supplied with the product.
