Siemens PP500-EM - Granta 4422 Connections; Sipass Integrated ADD5100 Connections

Installation
23
Siemens Building Technologies
Fire Safety & Security Products 07.2008
11.2.4 Granta 4422 connections
This is how to connect to a Granta 4422 module. The Wiegand interface is used
which must be configured with the A2 Preset configuration.
The jumpers in the 4422 shall be set as follows:
JU1/JU4 = A
JU2/JU5 = B
JU3/JU6 = B
Use interface 300 when configuring in the system.
Granta Signal PP500
+V
V+
1 V+
0V
0V
2 0V
D1
Data 1
5 D1
D0
Data 0
4 D (D0)
Red LED
8 RED
Green LED
9 GREEN
Horn
10 HORN
Table 4 Granta 4422 connections
11.2.5 SiPass Integrated ADD5100 connections
ADD5100 Signal PP500
+12V
V+
1 V+
0V
0V
2 0V
D0
Data 0
4 D (D0)
D1
Data 1
5 D1
RED
Red LED
8 RED
GRN
Green LED
9 GREEN
Table 5 SiPass Integrated ADD5100 connections
