Reconfiguring the function
33
Siemens Building Technologies
Fire Safety & Security Products 07.2008
12.8.2 Example 2
z Do not swap position of secondary code (0 in hex)
z Next four digits always zero (0000 in hex)
z Next digit always zero (0 in hex)
z Data Hold active-low (0 in hex)
z Internal horn disabled (2 in hex)
z Hold-off time: 30 seconds (look up in table - B in hex)
z Wiegand leading parity disabled (0 in hex)
z Internal control of red/green LED (1 in hex)
z Secondary Code check enabled (msb zero). RDD: 60 seconds decimal (3C in
hex)
z 4101/4010 data output (interface number 59 in hex)
Write down the hex digits in order: 000000002B013C59
The Programmer doesn’t need the leading zeros, so the number you enter in 63-bit
display format is: 2B013C59 (hexadecimal).
NOTE
The reader will start to work normally only after the selected hold-off time has elapsed.
