VPN tunnel between SCALANCE M-800 and S612
3.2 Secure VPN tunnel with PSK
SCALANCE M-800 Getting Started
112 Getting Started, 06/2015, C79000-G8976-C337-04
3.2.3.4
Configuring VPN authentication
Procedure
1. Click on "Security" > "IPSec VPN" in the navigation area and on the "Authentication" tab
in the content area.
2. Configure the VPN authentication with the following settings:
Authentication
PSK
Local ID
no entry necessary
Remote ID External IP address of the S612, e.g. 162.168.184.2
PSK / PSK Confirmation 12345678
The key that you configured in the SCT.
3. Click "Set Values".
