Siemens SCALANCE M-800 Series User Manual

NETMAP with SCALANCE M-800
6.1 NETMAP for the local network
SCALANCE M-800 Getting Started
Getting Started, 06/2015, C79000-G8976-C337-04
207
Requirement
● The SCALANCE M-800 is connected to the WAN , refer to "Connecting SCALANCE M-
800 to the WAN (Page 81)".
● The SCALANCE M-800 can be reached via the Admin PC and you are logged in to the
WBM as "admin".
Steps in configuration
The following steps are necessary to create NETMAP rules:
1. Creating a VPN connection (Page 207)
2. Creating NETMAP rules (Page 209)
6.1.1
Creating a VPN connection
Procedure
1. Click on "Security" > "IPSec VPN" in the navigation area and on the "General" tab in the
content area.
2. Select "Activate IPSec VPN" and click "Set Values".
3. Click on the "Remote End" tab in the content area and create the VPN partner with the
following settings:
On the M816
On the M876
Remote End Name
M876
M816
Remote Mode
Standard
Standard
Remote Typ
manual
manual
Remote Address Reachable via a dynamic DNS
service, e.g. example.no-ip.com
Fixed IP address (WAN IP address) of
the M816, e.g. 91.19.6.84
Remote Subnet
192.168.200.0/24
192.168.10.0/24
4. Click on the "Connections" tab in the content area and create the VPN connection with
the following settings:
On the M816
On the M876
Connection Name
M816_to_M876
M876_to_M816
Operation
disable
disable
Keyping Protocol
IKv2
IKv2
Remote End Name
M876
M816
Local Subnet
192.168.10.0/24
192.168.20.0/24
