VPN tunnel between SCALANCE M87x and SINEMA RC Server
5.4 Configuring a remote connection on the M87x
SCALANCE M-800 Getting Started
Getting Started, 06/2015, C79000-G8976-C337-04
199
Configuring a VPN connection to the SINEMA RC Server
Requirement
● A valid KEY-PLUG is inserted in the M87x.
1. Change to Web browser 1.
– Click "System" > "SINEMA RC" in the navigation area.
– For "Sinema RC Address", enter the WAN IP address of the SINEMA RC Server, see
table "Settings used (Page 181)".
2. Change to Web browser 2.
– In the navigation area, click "Remote connections" > "Devices".
– Click on the symbol
in "Actions" to open the device information.
– Holding down the left mouse button, select the entry for device ID.
– Right-click on the selection and in the shortcut menu, select the copy command.
3. Change to Web browser 1.
– Right click in the input box of "Device ID".
– In the shortcut menu, select the menu command for inserting.
– For "Device Password" enter the password that you configured for access, An:t_010
for M874-1 and An:t_020 for M874-2.
– Enable "Auto Firewall / NAT Rules".
When enabled, the suitable NAT and firewall rules are created automatically.
In "Verification Type", select "CA Certificate".
