Siemens SCALANCE M-800 Series User Manual

NETMAP with SCALANCE M-800
6.3 NETMAP for the local and remote network
SCALANCE M-800 Getting Started
218 Getting Started, 06/2015, C79000-G8976-C337-04
4. Click on the "Connections" tab in the content area and create the VPN connection with
the following settings:
On the M816
On the M876
Connection Name
M816_to_M876
M876_to_M816
Operation disable disable
Keyping Protocol
IKv2
IKv2
Remote End Name M876 M816
Local Subnet
192.168.10.0/24
192.168.20.0/24
5. Click on the "Authentication" tab in the content area and configure the VPN authentication
with the following settings:
On the M816
On the M876
Authentication
PSK
PSK
Local ID
-
-
Remote ID
-
-
PSK / PSK Confirma-
tion
e. g. 12345678 e. g. 12345678
6. Click on the "Phase 1" tab in the content area and configure the following settings:
M816 / M876
DPD
enabled
Encryption AES256 CBC (M87x)
AES256 (M81x)
Authentication
SHA512
IKE Key Derivation
DH group 14
Lifetime [min]
1440
DPD timeout [sec]
60
Aggressive Mode
no
7. Click on the "Phase 2" tab in the content area and configure the following settings:
M816 / M876
Encryption AES256 CBC (M87x)
AES256 (M816)
Authentication
SHA512
IKE Key Derivation
DH group 14
Lifetime [min]
1440
Result
The VPN connection on the devices is configured. To establish the VPN connection, click on
the "Connection" tab in the content area.
