VPN tunnel between SCALANCE M-800 and S612
3.1 Procedure in principle
SCALANCE M-800 Getting Started
Getting Started, 06/2015, C79000-G8976-C337-04
93
Settings used
For the configuration example, the devices are given the following IP address settings
Internal address
External address
Internal network
1
M-800 192.168.100.1
255.255.255.0
Fixed IP address, e.g. 90.90.90.90
Provider dependent
As an alternative, the DDNS host-
name can also be used.
Admin PC 192.168.100.20
255.255.255.0
Internal network
2
DSL router 192.168.184.254
255.255.255.0
Fixed IP address (WAN IP address),
e.g. 91.19.6.84
S612 Internal port
192.168.11.2
255.255.255.0
External port
192.168.184.2
255.255.255.0
PC 192.168.11.100
255.255.255.0
Requirement
● SCALANCE S612 is connected to the Internet via the DSL router.
On the DSL router, the PORT forwarding must be set so that the UDP packets from the
Internet addressed to ports 500 and 4500 of the router are sent to ports 500 and 4500 of
the connected SCALANCE S612 (passive module).
● The SCALANCE M-800 is connected to the WAN , refer to "Connecting SCALANCE M-
800 to the WAN (Page 11)".
● The SCALANCE M-800 can be reached via the Admin PC and you are logged in to the
WBM as "admin".
