Description of the device
3.3 SELECT / SET button
SCALANCE XC-200
26 Operating Instructions, 07/2016, C79000-G8976-C442-01
SELECT / SET button
Position
The "SELECT/SET" button is located on the front of the device.
Figure 3-1 Position of the button "SELECT/SET", for example on the SCALANCE XC208
To set the required display mode, press the "SELECT/SET" button.
For more detailed information on the display modes, refer to the section "LEDs "DM1" and
"DM2" (Page 30)".
Resetting the device to factory defaults
If you reset, all the settings you have made will be overwritten by factory defaults.
An inadvertent reset can cause disturbances and failures in the configured network.
