Page #59 background imageLoading...
Page #59 background image
SCALANCE XC-200
Operating Instructions, 07/2016, C79000-G8976-C442-01
59
Technical specifications
7
7.1
Technical specifications SCALANCE XC206-2 (ST/BFOC)
The following technical specifications apply to the SCALANCE XC206-2 (ST/BFOC).
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors Quantity 6
Connector RJ-45 jack
Properties Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Optical connectors
Quantity
2
Connector
ST/BFOC socket
Properties
Full duplex acc. to 100Base-FX
Transmission speed
100 Mbps
Cable type
Multimode glass FO cable
Transmitter output (optical)
Minimum
Maximum
-19 dBm
-14 dBm
Receiver input
Sensitivity min.
Input power max.
-32 dBm
-3 dBm
Cable cross-section
50/125 μm
62.5/125 μm
Cable length
0 ... 5 km
0 ... 5 km
Attenuation
1 dB/km at 1310 nm; 1200 MHz * km
1 dB/km at 1310 nm; 1200 MHz * km
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Electrical data
Power supply
1)
Rated voltage
12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Voltage
(SELV)
Design
Terminal block, 4 terminals
Properties
Implemented redundantly
Current consumption
12 VDC
500 mA
24 VDC
250 mA
Effective power loss
6 W
Fusing
2.5 A / 125 V
