Page #72 background imageLoading...
Page #72 background image
Technical specifications
7.9 Switching properties
SCALANCE XC-200
72 Operating Instructions, 07/2016, C79000-G8976-C442-01
7.9
Switching properties
The following technical specifications apply to the following devices:
SCALANCE XC206-2 (ST/BFOC)
SCALANCE XC206-2 (SC)
SCALANCE XC206-2SFP
SCALANCE XC208
SCALANCE XC216
SCALANCE XC224
Switching properties
Switching technique
Store and forward
Latency
10 microseconds
Full wire speed switching
Frame length (bytes)
Number of frames per second (at 100 Mbps)
64
148810
128
84459
256
45290
512
23496
1024
11973
1280
9615
1518
8127
Note
The number of SCALANCE XC
-200 modules connected in a line influences the entire frame
delay. When a frame passes through the IE switch, this is delayed by the store
-and-forward
function of the SCALANCE XC
-200 by 10-130 microseconds (at 100 Mbps).
