Page #63 background imageLoading...
Page #63 background image
Technical specifications
7.3 Technical specifications SCALANCE XC206-2SFP
SCALANCE XC-200
Operating Instructions, 07/2016, C79000-G8976-C442-01
63
7.3
Technical specifications SCALANCE XC206-2SFP
The following technical specifications apply to the SCALANCE XC206-2SFP.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors
Quantity
6
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Slots for pluggable transceivers
Quantity
2
Connector
SFP transceivers (LC port)
Transmission speed
100 / 1000 Mbps
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Electrical data
Power supply
1)
Rated voltage
12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Voltage
(SELV)
Design
Terminal block, 4 terminals
Properties
Implemented redundantly
Current consumption 12 VDC
Without SFP
400 mA
With SFP
2)
500 mA
24 VDC
Without SFP
200 mA
With SFP
2)
250 mA
Effective power loss
Without SFP
4.8 W
With SFP
2)
6 W
Fusing 2.5 A / 125 V
Signaling contact
1)
Quantity
1
Design
Terminal block, 2 terminals
Permitted voltage range
24 VDC
Load capability
max. 100 mA
Permitted ambient conditions
Ambient temperature
3)
During operation up to 2000 m
-40 °C to +70 °C
During storage
-40 to +85
During transportation
-40 to +85
Relative humidity
During operation at 25
95 % no condensation
Housing, dimensions and weight
Design
compact
Housing material
Basic housing
Die cast aluminum, powder coated
Front cover
Polycarbonate (PC-GF10)
Degree of protection
IP20
