Technical specifications
7.2 Technical specifications SCALANCE XC206-2 (SC)
SCALANCE XC-200
Operating Instructions, 07/2016, C79000-G8976-C442-01
61
7.2
Technical specifications SCALANCE XC206-2 (SC)
The following technical specifications apply to the SCALANCE XC206-2 (SC).
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors
Quantity
6
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Optical connectors
Quantity
2
Connector
SC socket
Properties
Full duplex acc. to 100Base-FX
Transmission speed
100 Mbps
Cable type
Multimode glass FO cable
Transmitter output (optical)
• Minimum
• Maximum
• -19 dBm
• -14 dBm
Receiver input
• Sensitivity min.
• Input power max.
• -32 dBm
• -3 dBm
Cable cross-section
• 50/125 μm
• 62.5/125 μm
Cable length
• 0 ... 5 km
• 0 ... 5 km
Attenuation
• ≤ 1 dB/km at 1310 nm; 1200 MHz * km
• ≤ 1 dB/km at 1310 nm; 1200 MHz * km
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Electrical data
Power supply
1)
Rated voltage
12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Voltage
(SELV)
Design
Terminal block, 4 terminals
Properties
Implemented redundantly
Current consumption 12 VDC 500 mA
24 VDC 250 mA
Effective power loss
6 W
Fusing
2.5 A / 125 V
Signaling contact
1)
Quantity
1
Design
Terminal block, 2 terminals
Permitted voltage range
24 VDC
Load capability
max. 100 mA
