Mounting
4.6 Wall mounting
SCALANCE XC-200
44 Operating Instructions, 07/2016, C79000-G8976-C442-01
Wall mounting
Preparation
Note the position of the securing bar, see also section “Dimension drawings SCALANCE XC-
200 (Page 73)“.
When supplied, the securing bar is in the wall mounting position. You do not need to prepare
the device any further.
If the securing bar is in the rail mounting position, note the section “Changing the position of
the securing bar (Page 45)“.
To mount the device on a wall, you require the following:
● 2 wall plugs
● 2 fillister head screws
Note
Depending on the mounting surface, use suitable fittings.
Note
The wall mounting must be capable of supporting at least four times the weight of the device.
To mount the device on a wall, follow the steps below:
1. Prepare the wall mounting with drilled holes and plugs. For the precise dimensions, refer
to the section "Dimension drawings (Page 73)".
2. Turn the upper screw in to the wall so that 10 mm remains jutting out.
3. Hang the device with the keyhole hanging mechanism on the rear on the screw.
4. Fix the device to the wall with the lower screw.
5. Connect the electrical connecting cables, refer to the section "Connecting up (Page 47)".
