Siemens SCALANCE XC-200 - Technical Specifications of the SCALANCE XC208

Technical specifications
7.4 Technical specifications of the SCALANCE XC208
SCALANCE XC-200
Operating Instructions, 07/2016, C79000-G8976-C442-01
65
7.4
Technical specifications of the SCALANCE XC208
The following technical specifications apply to the SCALANCE XC208.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors
Quantity
8
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Electrical data
Power supply
1)
Rated voltage
12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Volt-
age (SELV)
Design
Terminal block, 4 terminals
Property
Implemented redundantly
Current consumption
12 VDC
350 mA
24 VDC
175 mA
Effective power loss
4.2 W
Fusing
2.5 A / 125 V
Signaling contact
1)
Quantity
1
Design
Terminal block, 2 terminals
Permitted voltage range
24 VDC
Load capability
max. 100 mA
Permitted ambient conditions
Ambient temperature During operation up to 2000 m -40 °C to +70 °C
During storage
-40 ℃ to +85 ℃
During transportation
-40 ℃ to +85 ℃
Relative humidity
During operation at 25 ℃
≤ 95 % no condensation
Housing, dimensions and weight
Design
compact
Housing material
Basic housing
Die cast aluminum, powder coated
Front cover
Polycarbonate (PC-GF10)
Degree of protection
IP20
Dimensions (W x H x D)
60 x 147 x 125 mm
Weight
520 g
