Connecting up
5.3 Power supply
SCALANCE XC-200
Operating Instructions, 07/2016, C79000-G8976-C442-01
51
Position and assignment
Figure 5-1 Position of the power supply based on the example of the SCALANCE XC208 and the
assignment of the terminal block
Contact
Assignment
L1+
24 VDC
M1
Ground
M2
Ground
L2+
24 VDC
