Siemens SCALANCE XF200 - Optical Attachments to Industrial Ethernet; Multimode Fiber-Optic Cable

Connecting up
5.5 Attachment to Industrial Ethernet
SCALANCE X-200
Operating Instructions, 03/2015, C79000-G8976-C284-06
55
5.5.2
Optical attachments to Industrial Ethernet
5.5.2.1
Multimode fiber-optic cable
Transmission medium
The following X-200 IE switches use multimode fiber-optic cables as the transmission
medium:
● X204-2
● X204-2TS
● X204-2FM
● X206-1
● X212-2
● XF204-2
● XF206-1
● X202-2IRT
Characteristics:
Transmission speed
100 Mbps
Transmission mode
100Base-FX according to IEEE 802.3
Connectors BFOC sockets
Wavelength
1310 nm
Core diameter
50 or 62.5 μm
Outer diameter
125 μm
Light source
LED
Maximum range (segment length)
5 km
Note
No autonegotiation
With optical transmission, the full duplex mode and transmission
speed cannot be changed.
For this reason, the autonegotiation function cannot be selected.
