4.10 Data points
SIMATIC CC7
Operating Instructions, 10/2019, C79000-G8976-C503-02
107
Data types
Not every data type supports all trigger types. The table lists the configurable data types and
specifies the supported trigger types for each data type.
The tag "Data type alias" (DATAPOINT_TYPE) specifies the data type of the transferred
values when publishing the user data to the cloud, see section User data format (Page 89).
●
x : Supported
●
- : Not supported
Data types of the protocols
Data type alias
Operand area
Supported triggers
S7
type (bits)
Modbus
OPC
Time trigger /
Input trigger
Value trigger
BOOL (1)
- *
Boolean BOOL I, Q, M, DB
x
x
(only value 0)
BYTE (8)
- *
Byte
UINT8
I, Q, M, DB
x
x
CHAR (8)
- *
Byte CHAR I, Q, M, DB
x
x
SINT (8) ***
- *
SByte
INT8
I, Q, M, DB
x
x
USINT (8) ***
UInt8
Byte
UINT8
I, Q, M, DB
x
x
INT (16)
- *
Int16
INT16
I, Q, M, DB
x
x
UINT (16) ***
UInt16
UInt16
UINT16
I, Q, M, DB
x
x
WORD (16)
UInt16
UInt16
UINT16
I, Q, M, DB
x
x
REAL (32)
Float
Float
SINGLE_FLOAT
I, Q, M, DB
x
x
DWORD (32)
UInt32
UInt32
UINT32
I, Q, M, DB
x
x
DINT (32)
- *
Int32
INT32
I, Q, M, DB
x
x
UDINT (32) ***
UInt32
UInt32
UINT32
I, Q, M, DB
x
x
LREAL (64) ***
- *
Double
DOUBLE_FLOAT
I, Q, M, DB
x
x
LWORD (64) **
- *
UInt64
UINT64
I, Q, M, DB
x
x
LINT (64) **
- *
Int64
INT64
I, Q, M, DB
x
x
ULINT (64) **
- *
UInt64
UINT64
I, Q, M, DB
x
x
STRING (2..256 bytes)
-
String
S7_STRING
DB
x
-
DATE_AND_TIME (64)
****
-
DateTime S7_DT DB
x
-
DTL (96)
***
-
DateTime
*****
S7_DTL DB
x
-
*
See below, section "Modbus data types".
**
S7-1500 only
***
S7-1200/1500 only
****
S7-300/400/1500 only
***** The accuracy of the DTL (1 ns, 10
-9
seconds) is restricted to 100 ns (10
-7
seconds) for OPC DateTime.
Modbus data types
As standard, Modbus uses the data types "Bool" and "Word".
● The data type "Bool" is transferred from the application as "UInt8".
● The extended data types are transferred as 2 or 4 consecutive 16-bit registers.
